Description
| NO. | ITEM | TECHNICAL SPECIFICATION | ||||||
| 1. | SPECIFICATION
PARTS SPECIFICATION |
L×W×H | 1625*1060*1065 | |||||
| 2. | WHEELBASE | 1090±20mm | ||||||
| 3. | FRONT WHEELBASE | 820mm | ||||||
| 4. | REAR WHEELBASE | 830mm | ||||||
| 5. | MINIMUM GROUND CLEARANCE | 135±15mm | ||||||
| 6. | SEAT HEIGHT | 790±15 mm | ||||||
| 7. | RIDE HEIGHT | 225mm | ||||||
| 8. | HANDLE HEIGHT | 1000mm | ||||||
| 9. | PACKING SIZE | 1460*880*860mm 62pcs/40HQ | ||||||
| 10. | MINIMUM TURNING CIRCLE DIAMETER | 5900±500mm | ||||||
| 11. | TURNING ANGLE | <45° | ||||||
| 12. | RATED LOAD | 100kg | ||||||
| 13. | NET WEIGHT | 149kg | ||||||
| 14. | GROSS WEIGHT (WITH PACKING) | 177kg | ||||||
| 15. | F&R BRAKE | F&R HYDRAULIC DISC | ||||||
| 16. | F&R BRAKE OPERATION TYPE | FRONT HAND BRAKE, REAR FOOT BRAKE | ||||||
| 17. | F&R RIM | 10*5.5AT/9*8.0AT | ||||||
| 18. | F&R TYRE | AT20*7.0-10/AT19*10-9 | ||||||
| 19. | TRANSMISSION | CHAIN | ||||||
| 20. |
TECHNICAL SPECIFICATION |
FUEL TANK |
9L` | |||||
| 21. | ||||||||
| 22. | BATTRY | 12V/7HA ` | ||||||
| 23. | MAXIMUM SPEED | 70km/h | ||||||
| 24. |
SPECIFICATION |
STARTING PERFORMANCE | 15S | |||||
| 25. | CLIMBING PERFORMANCE | 21° | ||||||
| 26. | PARKING PERFORMANCE | ≥18° | ||||||
| 27. | EMISSION INDEX
|
CO (%) | ≤3.8 | |||||
| HC(PPm) | ≤800 | |||||||
| 28. | db.(A) | ≤82 dB(A) | ||||||
| 29. | ENGINE SPECIFICATION
|
MODEL | LC166FMM | |||||
| 30. | TYPE | SINGLE CYLINDER、250cc air cooler 2 valves、4-STROKE | ||||||
| 31. | BRAND | LONCIN | ||||||
| 32. | BRORE×STROKE | 65.5×66.2mm | ||||||
| 33. | capacity | 223mL | ||||||
| 34. | COMPRESSION RATIO | 9.0:1 | ||||||
| 35. | MAX.POWER | 12（1±5%）kW /7500（1±5%）rpm | ||||||
| 36. | MAX.TORQUE | 17（1±5%）N · m /6000（1±5%）rpm | ||||||
| 37. | Min no load speed | 1500（1±10%） r /min | ||||||
| 38. | min fuel consumption rate | 354g / kw.h | ||||||
| 39. | Fuel no. | ≥RQ90 | ||||||
| 40. | CLUTCH METHOD | Manual | ||||||
| 41. | Start | Electrical start | ||||||
| 42. | cdi | C.D.I | ||||||
| 43. | PARTS SPECIFICATION | carb | PZ30 | |||||
| 44. | Spark plug | D8TC | ||||||
| 45. | Front light | 12V18-18W | ||||||
| 46. |
TECHNICAL SPECIFICATION |
Max speed | 70km/h | |||||
| 47. | Start time | 15S | ||||||
| 48. | break | |||||||
| 前轮力和 | ≥60% | |||||||
| 前轮力差 | ≥55% | |||||||
| 后轮力和 | ≤20% | |||||||
| 后轮力差 | ≤24% | |||||||
| 49. | CLIMBING PERFORMANCE | 21°° | ||||||
| 50. | PARKING PERFORMANCE | ≥18% | ||||||
| 51. | EMISSION INDEX | CO (%) | ≤3.8 | |||||
| HC(PPm) | ≤800 | |||||||
| 52. | db(A) | ≤82 dB(A) | ||||||
| 53. | Starting acceleration（S） | ≤8 | ||||||
| 54. | Speed acceleration（S） | ≤8 | ||||||
| 55. | Parts spec | Tank capacity | 9L | |||||
| 56. | Fr. & re suspension | Oil dumper | ||||||
| 57. | Fr. &re suspension | L=350 m m /L=390 m m | ||||||
